P10 variable message signs(VMS)

( 2 Years Warranty variable message signs(VMS) )

Our Products

Features/Benefits Specifications Project Download

VMS variable message sign Benefits
The VMS display screen is an intelligent variable message screen and an electronic intelligent display panel for road trac management. It is not only used in traditional trac management elds such as expressways and urban roads, but also gradually expands to areas such as public transportation, logistics, advertising, etc. In the transportation eld, it can serve as a trac information board, trac guidance screen, road sign, lifting warning screen, etc., providing information such as road conditions, speed limits, and warnings. In the advertising eld, it can be used as a mobile advertising carrier.

FEATURES:
1·Energy saving and environmental protection, "0" noise, "0" pollution;

2.Easy operation and maintenance;

3.Quick and easy deployment;

4.Compact structure for long distance transportation;

VMS Display Screen Parameters:	NBVMS-V2-Y
Dimensions (height x width in )	1660 x 1020 mm
Screen resolution (height x width )	160 x 96 pixels
Display color	Full color (red, green, blue, white, etc.)
Pixel spacing (mm)	10
Module type	P10 outdoor waterproof screen
Module brightness	≥ 8000cd/m2
Pixel composition	30° 1R1G1B Red: Jingyuan , Green: Shilan, Blue: Shilan
Single LED rated current luminous intensity	R: 800mcd, G: 2500mcd, B：450mcd
Viewing angle	110 degrees horizontally, 50 degrees vertically
Display content	text, images, GIF,video
Parameter settings	Supports Android (APP), Apple (IOS), PC (PC)
Rated voltage	24V
Whole machine power consumption	≤ 1060W
Temperature range	-20 ° C -+60 ° C
Protection level	IP 54
Lifespan	100000 hours
Communication methods	Ethernet or WIFI
Adjustable brightness	1-16 levels
