Home > Our Product >Traffic camera > Red Light Capture camera
Features/Benefits Specifications Project Download
  • DISTRIBUTION:

    NobTra AI traffic detection camera is an integrated video traffic information collection device suitable for outdoor environments. It collects traffic data, detects traffic vehicles, and optimizes traffic signal control systems in highways, tunnels, urban intersections and sections.NobTra intelligent red light capture camera is developed for traffic management at urban intersections.Equipped with a high-definition imaging module,it delivers high-precision recognition around the clock.

    Meeting relevant protection standards,the device withstands harsh outdoor conditions including extreme temperatures,rain and dust. It can accurately capture license plates and full vehicle profiles of red-light-running vehicles,and automatically store evidence images of violations.

    Supporting linkage with traffic signal controllers,it enables stable automatic capture of red-light violations, facilitating standardized management of traffic order at intersections. It is widely applied to urban arterial roads,cross intersections,park roads and other scenarios.

  • Product Advantages:

    Simple Retrofit,No Intersection Rebuilding.Only add capture cameras &loop sensers;reuse existing poles and cables to cut construction time.

    Each violation snapshot auto-stamps red-light violation proof,plate,car color,timestamp &site info for complete legal evidence.

    ≥95% day and ≥90% night plate recognition, images meet official law enforcement standards.

Comprehensive License Plate Recognition Rate ≥97%
Power Vehicle presence
Detection Zones <5W
Waterpro of Level IP65
Working Temperature -30 degree to 75 degree
Working Voltage 100-240VAC/12VDC
Recognition Algorithmt Recognition Angle Max 65° horizontal, max 60° vertical
Stable Recognition Rate for License Plates at Wide Angles ≥97%
Recognition Distance 18m ~ 35m
Optimal Usage Distance Optimal Usage Distance
Supported License Plate Types Supports license plates from Taiwan (China), Brazil, Singapore, Vietnam, Malaysia, Europe, Thailand, Hong Kong (China), Macao (China), Chile, Colombia, South Africa, Dubai and other regions/countries
License Plate Recognition Features Number, Color,Type, Width
Video Video Resolution 315mm*145mm*103MM
Video Compression Standard Optional
Compression Bitrate Output 12-42VDC
Frame Rate TCP/IP、MQTT、RTSP
HTTP Push Supported; supports uploading recognition results & oine retransmission
Imaging Image Sensor 3MP Starlight CMOS
Eective Resolution 2304*1296
Standard Lens 5-50mm varifocal lens
Interface Ethernet Port 1 x 10/100Mbps adaptive RJ45 port
TF Card Slot 1 TF card slot, max. 64GB capacity supported
Reset Key 1 RESET button
Parameters Overall Dimensions Complete unit:443mm*146mm*105mm
